MIKUNI

We are dedicated reciprocating compressor and vacuum pump manufacturer which our products are working for boost, pumping, absorption etc. for almost whole of industries.

DN Series

Single Stage

Cylinder bore: 60-400mm

Stroke: 75-180mm

Piston displacement: 0.1-19m3/min

Req. power: 1.5-55kW

BOG Gas

  • DN6-25BG2

  • 0.85 MPaG

  • 55kW

NH3 Gas

  • DN6-18B2G2

  • 1.5 MPaG

  • 45kW

N2 Gas

  • DN4-08B3G

  • 0.6 MPaG

  • 15kW

Multi Stage

Cylinder bore: 40-290mm

Stroke: 100-180mm

Piston displacement: 0.1-6m3/min

Req. power: 1.5-55kW

He Gas

  • DNS6-1609B3G2

    DNS7-0803FB13G2

  • 20 MPaG

  • 37kW

NH3 Gas

  • DN6-18B2G2

  • 1.5 MPaG

  • 45kW

H2 Gas

  • DNS4-1307B2G2

  • 2.5 MPaG

  • 11kW

DYN Series

Single Stage

Cylinder bore: 80-550mm

Stroke: 150-180mm

Piston displacement: 0.8-85m3/min

Req. power: 20-300kW

CO Gas

  • DYN6-29G2

  • 0.3 MPaG

  • 55kW

O2 Gas

  • DYN7-44G2

  • 0.2 MPaG

  • 85kW

Multi Stage

Cylinder bore: 40-530mm

Stroke: 150-180mm

Piston displacement: 0.5-39m3/min

Req. power: 50-300kW

N2 Gas

  • DYNS6-12F090503FB3G

  • 20 MPaG

  • 37kW

CH4 Gas

  • DYN6-2714G2

  • 2.2 MPaG

  • 65kW

OPN Series

Single Stage

Cylinder bore: 80-700mm

Stroke: 160-300mm

Piston displacement: 1-330m3/min

Req. power: 50-2000kW

CO2 Gas

  • OPN83-37B2G2

  • 2.2 MPaG

  • 460kW

H2 Gas

  • 2OPN92-50B2G2

  • 0.95 MPaG

  • 1250kW

Multi Stage

Cylinder bore: 40-530mm

Stroke: 150-180mm

Piston displacement: 0.5-39m3/min

Req. power: 50-300kW

N2 Gas

  • OPN82N-5531G2

  • 1.7 MPaG

  • 370kW

CH4 Gas

  • OPN6-4121CL

  • 1.8 MPaG

  • 135kW

Vacuum pump

Cylinder bore: 360-780mm

Stroke: 130-230mm

Piston displacement: 11.8-71.2m3/min

Ultimate vacuum: 96-98%

Req. power: 15-75kW

Air

  • PHNL-226H

  • 45kW

Cylinder bore: 360-780mm

Stroke: 130-230mm

Piston displacement: 11.8-71.2m3/min

Ultimate vacuum: 96-98%

Req. power: 15-75kW

Air

  • SH-115H

  • 11kW

Special Machines

Four-Stages

  • VA-HH1

  • 24.5MPaG

  • Four-stage / For airtight test

Two-Stages

  • VH-1112B

  • 5MPaG

  • Two-stage / For airtight test.

High Pressure Air Compressor

Five-Stages

  • SW4-13100502F01F

  • 45MPaG

  • Five-stage / For airtight test.

Two-Stages

  • SV5-2010G

  • 1.5MPaG

  • Two-stage / For natural gas lift.

Three-Stages

  • 2SV6-231509G

  • 5MPaG

  • Three-stage / For natural gas lift.

Special Compressor for Nitrogen Purging

  • DYN7-16B2G

  • Floating offshore natural gas liquefaction equipment.

Compressor for Liquefield Gas Transfer

  • DNL-710HB2GST21

  • Floating offshore natural gas liquefaction equipment.

  • SNL-5MUVA

  • This compressor is designed for liquefied ammonia gas transfer.

Special Hydrogen Gas Compressor

  • 20PN92-50B2G2

  • This is designed to compress hydrogen gas containing trichlorosilane (SiHCl 3) for the manufacture of polysilicon for semiconductor and photovoltaic power system.

Vacuum Pump for Nuclear Power Plant

  • VPQ-50G7ST4

  • This leak-proof special vacuum pump was developed for sampling and radioactive gasses.
