Seal-less Diaphragm Pumps

About

Hydra-Cell positive displacement diaphragm pumps feature a seal-less pumping chamber so there are no seals, packing or cups to leak or replace. The seal-less design and check valves enable Hydra-Cell to handle abrasives and particulates that would damage other types of pumps.

In addition, Hydra-Cell can run dry indefinitely without damage to the pump.

The multiple-diaphragm design of Hydra-Cell provides virtually pulse-less, linear flow without the need for expensive pulsation dampeners.

Hydra-Cell® Principles of Operation

    • Drive Shaft: via electric motor, hydraulic motor, belt and pulley, etc.

    • Tapered Roller Bearings: rigid support, immersed in lubricating oil bath

    • Fixed Angle Cam/Wobble Plate: translates rotary motion into linear to the hydraulic cells

    • Hydraulic Cells (patented): displace diaphragms via pressurized oil

    • Diaphragms: hydraulic balanced, no stress during flexing

    • Inlet Valve Assembly: simple design, allows liquid into pump chamber

    • Discharge Valve Assembly: allows liquid to flow into pressure discharge line

    • C62 Pressure Regulating Valve: controls output pressure and prevents pump overload

Hydra-Cell® Model

F/M/D/H/G Series Seal-less Pumps

Versatile, Reliable Pumps for a Wide Range of Applications

    • Pumps the full spectrum of low-to-high viscosity fluids.

    • Features a seal-less design and horizontal disk check valves that enable the pump to handle abrasives and particulates that might damage or destroy other types of pumps.

    • Simple, compact design reduces initial investment and lowers maintenance costs.

    • Operational efficiencies reduce energy costs.

    • Able to run dry without damage to the pump

    • Tolerates non-ideal operating conditions.

    • Minimizes maintenance and downtime because there are no mechanical or dynamic seals, packing, or cups to leak, wear, or replace.

T & Q Series Seal-less Pumps

T and Q Series pumps feature the Hydra-Cell seal-less design, eliminating cleanup costs from leaking seals or packing and protecting operators from dangerous fluids such as those containing hydrogen sulfide.

    • Seal-less design separates the power end from the process fluid end, eliminating leaks, hazards, and the expense associated with seals and packing.

    • Low NPSH requirements allow for operation with a vacuum condition on the suction – positive suction pressure is not necessary.

    • Can operate with a closed or blocked suction line and run dry indefinitely without damage, eliminating downtime and repair costs.

    • Unique diaphragm design handles more abrasives with less wear than gear, screw or plunger pumps.

    • Hydraulically balanced diaphragms to handle high pressures with low stress.

    • Lower energy costs than other pump technologies.

    • Rugged construction for long life with minimal maintenance.

    • Compact design and double-ended shaft provide a variety of installation options.

P Series Seal-less Metering Pumps

Compact, cost-effective pump systems for high-performance metering applications

  • Hydra-Cell is not a conventional metering pump. Hydra-Cell Metering Solutions pumps enable you to meet and, in most cases, exceed API 675 performance standards with virtually pulse-less, linear flow while providing many other operational benefits. Taking advantage of the most current technologies, Hydra-Cell P Series metering pumps achieve superior levels of accuracy, repeatability and linearity, while delivering precise, constant flow. This revolution in metering employs the latest available means of electronic flow control to replace antiquated, inaccurate stroke adjusters.

C Series Pressure Regulating Valves

Designed for use with any positive displacement pump, Hydra-Cell C Series pressure regulating valves bypass

Versatile Application for Positive Displacement Pumps

  • System fluid to prevent excess system pressure. They can also be used as pressure relief valves. When a system discharge is completely closed (e.g. closed spray gun, closed valve, plugged nozzle) the Hydra-Cell valve bypasses the total system fluid flow. The valves also balance system pressure for multiple-gun operations. Hydra-Cell C Series valves can be serviced in place without removing any fittings or plumbing. Simply remove the top of the body and replace any worn internal components.

Hydra-Cell® Primary Pumping Applications

Hydra-Cell pumps operate reliably and efficiently in commercial, institutional, industrial, and municipal facilities throughout the world. The breadth of the product line offers a wide range of flow capacities and pressure ratings to meet many different requirements.

    • Blending

    • Coating

    • Dosing

    • Filtering

    • Metering

    • Spraying

    • Cleaning

    • Cooling

    • Filling

    • Injecting

    • Mixing

    • Transferring

    • Polyurethane Processing

    • Food

    • Pharmaceutical

    • Oil Recovery

  • High-precision injecting at low flow rates can be achieved for specialized applications in polyurethane processing.

  • Pumping for waste stream reduction and salt solution concentration at a pharmaceutical chemical plant.

  • Hydra-Cell pumping shear-sensitive polymers for enhanced oil recovery.

  • Hydra-Cell pumps used for ultra-filtration by a food additive manufacturer.
